輸入阻抗Input Impedance                                        50(Ω)

駐波比系數(shù) VSWR                                                      <1.5

增益Gain                                                                  15(dBi)

半功率波束（3dB）HPBW                                          65°H-Plane        13°E-Plane

前后比F/B                                                                 >25(dB)

功率容量 Maximum Power                                        500(W)

極化方式Polarization                                                垂直極化Vertical Polarization

交調(diào) PIN                                                                  <-107(dBm)

接口Connector Protection                                       7/16或N-K

閃電保護Light Protection                                         直接接地Direct Ground

抗風(fēng)Wind Velocity                                                   200(km/h)

高/寬/厚Height/Wide/Depth                                    785/165/55(mm)

重量Weight                                                             2.8(kg)

抱桿直徑Hold Pole Diameter                                   50-110(mm )
